Floor heating and cooling
Space heating with radiators
Cooling and heating with fan coils.
Domestic hot water
Features:
The heating system has been custom-designed to cater to tropical and subtropical climates, specifically in regions like Southeast Asia, South Africa, South Europe, and other similar areas. Its heat pump technology generates hot water with temperatures up to 60ºC, making it suitable for both radiator and underfloor heating.
Incorporated in the system's design is an intelligent EE valve that works efficiently in different ambient temperatures, ensuring consistent performance throughout the year. The motherboard is designed as a plug-and-play system, making it easy to service and reducing downtime and maintenance costs.
The system's fan motor operates with exceptional efficiency and quietness, creating a comfortable and peaceful living environment. Additionally, the R410a system is available to further enhance the product's cooling and heating capabilities.
This heating system provides an all-in-one solution for households, providing not only cooling and heating but also sanitary hot water. It uses a full inverter, delivering high performance and energy efficiency, making it a cost-effective option for homeowners.
The use of air source heat pumps for domestic heating has become increasingly popular due to their efficiency and sustainability. These pumps operate by extracting warmth from the outside air and using it to heat or cool a building's interior spaces, making them an excellent choice for both new and existing homes. By utilizing renewable energy sources, such as heat pumps, homeowners can enjoy cost-effective and reliable heating solutions while reducing their carbon footprint. Heat pumps are an excellent investment for anyone looking to incorporate sustainable heating methods into their homes, making them an ideal choice for anyone in need of a reliable and cost-effective heating solution.
Unlike traditional heat pump with single-speed compressor which by switching on and off periodically to adjust the performance of the heating & cooling, full inverter heat pump uses a variable speed compressor which can automatically all adjust the output needed at the lowest consumption of power and maintain the best temperature at different climatic conditions. When the heating demand is high, the inverter compressor and fan motor will start running at a high speed and, inversely, they will run at a low speed.
Achieve an extremely high COP
Shorten heating time.
Greatly save energy and cut down electricity bill
Contribute to a quiet neighbor environment
Floor heating and cooling
Space heating with radiators
Cooling and heating with fan coils.
Domestic hot water
Features:
The heating system has been custom-designed to cater to tropical and subtropical climates, specifically in regions like Southeast Asia, South Africa, South Europe, and other similar areas. Its heat pump technology generates hot water with temperatures up to 60ºC, making it suitable for both radiator and underfloor heating.
Incorporated in the system's design is an intelligent EE valve that works efficiently in different ambient temperatures, ensuring consistent performance throughout the year. The motherboard is designed as a plug-and-play system, making it easy to service and reducing downtime and maintenance costs.
The system's fan motor operates with exceptional efficiency and quietness, creating a comfortable and peaceful living environment. Additionally, the R410a system is available to further enhance the product's cooling and heating capabilities.
This heating system provides an all-in-one solution for households, providing not only cooling and heating but also sanitary hot water. It uses a full inverter, delivering high performance and energy efficiency, making it a cost-effective option for homeowners.
The use of air source heat pumps for domestic heating has become increasingly popular due to their efficiency and sustainability. These pumps operate by extracting warmth from the outside air and using it to heat or cool a building's interior spaces, making them an excellent choice for both new and existing homes. By utilizing renewable energy sources, such as heat pumps, homeowners can enjoy cost-effective and reliable heating solutions while reducing their carbon footprint. Heat pumps are an excellent investment for anyone looking to incorporate sustainable heating methods into their homes, making them an ideal choice for anyone in need of a reliable and cost-effective heating solution.
Unlike traditional heat pump with single-speed compressor which by switching on and off periodically to adjust the performance of the heating & cooling, full inverter heat pump uses a variable speed compressor which can automatically all adjust the output needed at the lowest consumption of power and maintain the best temperature at different climatic conditions. When the heating demand is high, the inverter compressor and fan motor will start running at a high speed and, inversely, they will run at a low speed.
Achieve an extremely high COP
Shorten heating time.
Greatly save energy and cut down electricity bill
Contribute to a quiet neighbor environment
Market model | WW09V | WW14V | WW18V | WW25V | WW30V | ||
Heating Working Condition A 7ºC/ 6ºC W 30-35ºC | Output Capacity | Kw | 9.8 | 14 | 18.4 | 25.3 | 30.1 |
Input Power | Kw | 2.4 | 3.3 | 4.3 | 6.2 | 5.3 | |
COP | - | 10.6 | 5.9 | 7.1 | 11.3 | 12.6 | |
Input Current | A | 4.1 | 4.3 | 4.3 | 4.1 | 4 | |
Heating Working Condition A 20ºC/ 15ºC W 40-45ºC | Output Capacity | Kw | 11.3 | 18.4 | 21.8 | 29.5 | 36.2 |
Input Power | Kw | 2.9 | 4.6 | 5.2 | 7.4 | 9.3 | |
COP | - | 13 | 7.8 | 8.4 | 12.7 | 15.4 | |
Input Current | A | 3.9 | 4 | 4.2 | 4 | 3.9 | |
Cooling Working Condition A 35ºC/ 25ºC W 12-7ºC | Output Capacity | Kw | 6.7 | 10.4 | 13.1 | 19.3 | 22.4 |
Input Power | Kw | 2.6 | 3.8 | 5.1 | 7.3 | 8.1 | |
COP | - | 11.3 | 6.8 | 8.5 | 12.6 | 13.6 | |
Input Current | A | 2.6 | 2.7 | 2.6 | 2.7 | 2.8 | |
Power Supply | V/PH/HZ | 220V/1/50HZ | 380V/3/50HZ | 380V/3/50HZ | 380V/3/50HZ | 380V/3/50HZ | |
Electric heater | Kw | 1.5 | 4 | 4 | 6 | 6 | |
internal expansion tank size | L | 5 | 8 | 8 | 12 | 12 | |
Refrigerant Type | - | R410A | R410A | R410A | R410A | R410A | |
Max Water Temperature | ºC | 60 | 60 | 60 | 60 | 60 | |
Working Ambeint Temperature | ºC | -10~43 | -10~43 | -10~43 | -10~43 | -10~43 | |
Water Flow Rate(ΔT 5ºC) | m³/h | 2 | 2.7 | 3.7 | 5.2 | 6.2 | |
Water connection | inch | G1" | G1" | G1" | G1.5" | G1.5" | |
Circulation pump | pcs | 1 | 1 | 1 | 1 | 1 | |
Compressor number | pcs | 1 | 1 | 1 | 1 | 1 | |
Fan number | pcs | 1 | 1 | 1 | 1 | 1 | |
Sound pressure Level @1m | dB(A) | 54 | 56 | 57 | 58 | 58 | |
Net Dimension (L*W*H) | mm | 1165*410*800 | 1165*410*1000 | 1150*440*1350 | 1165*430*1550 | 1165*430*1550 |
Market model | WW09V | WW14V | WW18V | WW25V | WW30V | ||
Heating Working Condition A 7ºC/ 6ºC W 30-35ºC | Output Capacity | Kw | 9.8 | 14 | 18.4 | 25.3 | 30.1 |
Input Power | Kw | 2.4 | 3.3 | 4.3 | 6.2 | 5.3 | |
COP | - | 10.6 | 5.9 | 7.1 | 11.3 | 12.6 | |
Input Current | A | 4.1 | 4.3 | 4.3 | 4.1 | 4 | |
Heating Working Condition A 20ºC/ 15ºC W 40-45ºC | Output Capacity | Kw | 11.3 | 18.4 | 21.8 | 29.5 | 36.2 |
Input Power | Kw | 2.9 | 4.6 | 5.2 | 7.4 | 9.3 | |
COP | - | 13 | 7.8 | 8.4 | 12.7 | 15.4 | |
Input Current | A | 3.9 | 4 | 4.2 | 4 | 3.9 | |
Cooling Working Condition A 35ºC/ 25ºC W 12-7ºC | Output Capacity | Kw | 6.7 | 10.4 | 13.1 | 19.3 | 22.4 |
Input Power | Kw | 2.6 | 3.8 | 5.1 | 7.3 | 8.1 | |
COP | - | 11.3 | 6.8 | 8.5 | 12.6 | 13.6 | |
Input Current | A | 2.6 | 2.7 | 2.6 | 2.7 | 2.8 | |
Power Supply | V/PH/HZ | 220V/1/50HZ | 380V/3/50HZ | 380V/3/50HZ | 380V/3/50HZ | 380V/3/50HZ | |
Electric heater | Kw | 1.5 | 4 | 4 | 6 | 6 | |
internal expansion tank size | L | 5 | 8 | 8 | 12 | 12 | |
Refrigerant Type | - | R410A | R410A | R410A | R410A | R410A | |
Max Water Temperature | ºC | 60 | 60 | 60 | 60 | 60 | |
Working Ambeint Temperature | ºC | -10~43 | -10~43 | -10~43 | -10~43 | -10~43 | |
Water Flow Rate(ΔT 5ºC) | m³/h | 2 | 2.7 | 3.7 | 5.2 | 6.2 | |
Water connection | inch | G1" | G1" | G1" | G1.5" | G1.5" | |
Circulation pump | pcs | 1 | 1 | 1 | 1 | 1 | |
Compressor number | pcs | 1 | 1 | 1 | 1 | 1 | |
Fan number | pcs | 1 | 1 | 1 | 1 | 1 | |
Sound pressure Level @1m | dB(A) | 54 | 56 | 57 | 58 | 58 | |
Net Dimension (L*W*H) | mm | 1165*410*800 | 1165*410*1000 | 1150*440*1350 | 1165*430*1550 | 1165*430*1550 |
